Hewi Duo Folding Grab Rail
WARM TOUCH unites the visual properties of high gloss chrome surfaces with the haptic properties of polyamide. The products feel pleasantly warm and therefore contribute to the user's feeling of well-being. Due to this property, WARM TOUCH products are especially suitable for patients with increased sensitivity to cold, for example, those who have rheumatic disorders.
The tubular design enables symmetrical gripping. The chrome-look coating process not only enables a fine look with high degree of gripping comfort, but also an extremely resistant surface. The products are finished using a special coating process.
Use the links below to download more information about this product:
Features and Benefits:
- Made of environmentally friendly, chrome-look coated polyamide
- With two gripping levels arranged above each other
- Bottom rail is merged with the top rail at an angle of 135°
- Loading capacity 100 kg (accessible to DIN 18040)
- Can be folded upwards and, with friction device, downwards
- With corrosion resistant steel core
- Integrated wall mounting plate made of metal with cap made of environmentally friendly, chrome-look coated polyamide
- Wall mounting plate 181 mm high and 130 mm wide
- Top rail ø 33 mm, bottom rail ø 25 mm
- Stable three-point fixing
- For wall mounting with special fixing material from HEWI
Supplied only with wall-specific HEWI fixing material (Stainless steel).
| Product | Finish | Code Number |
| Fixed 700mm | Chrome | P6836969 |
| Fixed 850mm | Chrome | P6836970 |
| Fixed 900mm | Chrome | P6836971 |
| Mobile 700mm | Chrome | P6836972 |
| Mobile 850mm | Chrome | P6836973 |
